描述
The Sonnoc SNP-LU18K is a flagship DLP laser engineering projector in Sonnoc’s Navigator Series, featuring ultra-high brightness, 0.96” large DMD, flagship motorized lens, full-range interchangeable lens, 720° installation, IP5X dustproof, 24/7 stable operation, making it the top main model for top large venues, ultra-high-end stage performances, outdoor giant screen shows, immersive cinemas, museums, command centers, cultural tourism night tours, water screen/mountain lighting.
Equipped with a 0.96” DMD chip, native WUXGA (1920×1200) resolution (16:10 wide screen), compatible with 4K signals (up to 4096×2160), delivering sharp text and clear details. 18000 lumens ensures bright, clear 800” ultra-large screens even in daylight. 3,000,000:1 extreme black dynamic contrast provides deep blacks and rich layers. Supports HDR10, 3D, HSG color management with independent adjustment of 7 primary colors for accurate, vibrant colors.
Motorized lens (standard): 1.46~2.95:1 throw ratio, 2.02× motorized zoom projects 100” at 3.0~6.0m; motorized lens shift (V +50%/-10%, H ±20%) with 5 lens memory presets + lens lock offers high installation tolerance without frequent adjustments. Full-range interchangeable lenses supported (ultra-short/short/standard/long/ultra-long) cover 0.36~10.08:1 ultra-wide throw ratio, fitting all scenarios from 50” small meetings to 800” super-large stages.
Dual-color laser (RgBL) diode module: 20,000hrs (normal) / 25,000hrs (eco) lifespan, slow brightness decay for long-term stability. IP5X dustproof reduces maintenance, supporting 24/7 continuous operation for high-intensity engineering scenarios.
Rich interfaces: HDMI×1, DVI-D, DisplayPort, HDBaseT, 3G-SDI, USB-A, RJ45, RS232, audio in/out, supporting 4-corner/curved/17-point geometric correction for complex fusion and irregular screens. 720° free rotation installation with built-in orientation sensor automatically identifies front/rear/ceiling projection, adapting to any angle: ceiling, floor, side, vertical.
Sleek black design, low noise (46dB normal / 40dB eco), stable cooling. 2×15W speakers deliver loud, clear sound. Widely used in top stadiums, international exhibition centers, high-end stage theaters, museums, immersive cinemas, curved/spherical fusion, outdoor giant screen shows, cultural tourism night tours, water screen lighting, command centers, security monitoring.
| 项目 Item | 中文规格 | English Specification |
|---|---|---|
| 型号 Model | SNP-LU18K | SNP-LU18K |
| 显示技术 | DLP 激光（0.96” DMD） | DLP Laser (0.96” DMD) |
| 分辨率 | WUXGA 1920×1200（16:10）兼容 4K | WUXGA 1920×1200 (16:10) 4K Compatible |
| 亮度 | 18000 流明 | 18000 Lumens |
| 投射比 | 1.46~2.95:1（2.02 倍电动变焦） | 1.46~2.95:1 (2.02× Motorized Zoom) |
| 100 寸距离 | 约 3.0~6.0 米 | Approx. 3.0~6.0m |
| 镜头位移 | 垂直 + 50%/-10%；水平 ±20%（电动） | V +50%/-10%; H ±20% (Motorized) |
| 可换镜头 | 支持全系列（超短焦 / 短焦 / 标准 / 长焦 / 超长焦） | Full-Range Optional (Ultra-Short/Short/Standard/Long/Ultra-Long) |
| 对比度 | 3,000,000:1（极致黑动态） | 3,000,000:1 (Extreme Black Dynamic) |
| 光源寿命 | 20000h (标准)/25000h (节能) | 20,000hrs(Normal)/25,000hrs(Eco) |
| 校正 | 四角、曲面、十七点几何校正 | 4-Corner, Curved, 17-Point Geometric Correction |
| 安装 | 720° 自由旋转（正投 / 背投 / 吊顶） | 720° Free Rotation (Front/Rear/Ceiling) |
| 防尘 | IP5X 过滤网 | IP5X Dust Filter |
| 接口 | HDMI×1、DVI-D、DisplayPort、HDBaseT、3G-SDI、USB-A、RJ45、RS232、音频入 / 出 | HDMI×1, DVI-D, DisplayPort, HDBaseT, 3G-SDI, USB-A, RJ45, RS232, Audio In/Out |
| 扬声器 | 15W×2 | 15W×2 |
| 尺寸 | 650×660×244 mm | 650×660×244 mm |
| 净重 | 约 23.75 kg | Approx. 23.75kg |
Supports B2B bulk purchasing and customization (boot logo/packaging/functions). Provides professional engineering solutions, OEM/ODM, stable supply and technical support to help integrators implement top large projects efficiently.
